Intel D945GCLF2D (with integrated Atom 2x 1.6Ghz CPU)

PRODUCT IS CURRENTLY NOT AVAILABLE !
Intel D945GCLF<b>2D</b> (with integrated Atom 2x 1.6Ghz CPU)
  • Intel Atom Silverthorne !
  • 2x 1.6Ghz !
  • Intel Rapid BIOS Boot

Intel D945GCLF2D : Like D945GCLF2, but without TV-Out !

Successor of Intel D945GCLF Mainboard. Differences :
- Dual Core Atom CPU
- 1000 Mbit LAN
- Additional onboard-USB-header
- 24pol ATX


The Atom-CPU is a perfect basis for a low-cost system. It works very energy saving and therfor is perfect for mobile usage. But also can be used as a server, Car-PC or Multimedia solutions.

Atom-CPU mainly was developed for the upcoming „Mobile Internet Devices“ (MID), which are fielded between notebooks and cell phones. „The processors were equipped in 45nm production with the worlds smallest transistors“
[more]

Share

CPU Intel Atom 330 2x 1.6Ghz
Graphics Intel GMA 950
Formfactor ITX (17x17cm)
RAM 1x DDR-II 533/667
Audio Realtek High Definition Audio
Base Intel ITX
USB 8x USB 2.0
Firewire --
IDE/SATA 1x IDE, 2x SATA
LAN 1x 10/100/1000 Mbit
Parallel 1x
Serial 1x
no TV-Out
yes PCI
no Mini-PCI
yes IDE
no DVI
yes 800x480 Resolution
no Passive-Cooling
no PCI-Express
no PCMCIA
yes SATA
no CPU changeable
no Compact Flash

Intel D945GCLF2D : Like D945GCLF2, but without TV-Out !

Successor of Intel D945GCLF Mainboard. Differences :
- Dual Core Atom CPU
- 1000 Mbit LAN
- Additional onboard-USB-header
- 24pol ATX


The Atom-CPU is a perfect basis for a low-cost system. It works very energy saving and therfor is perfect for mobile usage. But also can be used as a server, Car-PC or Multimedia solutions.

Atom-CPU mainly was developed for the upcoming „Mobile Internet Devices“ (MID), which are fielded between notebooks and cell phones. „The processors were equipped in 45nm production with the worlds smallest transistors“, said Intels Vice President Sean Maloney.

As IT-world currently is crying for „GreenIT“ schreit, this mainboard can be the answer. For example Intel was able to reduce the power consumption of the CPU from precessor D201GLY2 from 20W to 2.05W, which is really incredible ! Here other mainboards can not compete with !



Bootup-Durations :
- Cold boot : 29 sec.
- Standby : 3 sec.
- Hibernation : 21 sec.

Name D945GCLF
Form Factor Mini-ITX Mainboard
CPU Intel Atom 330 @ 2x 1.60GHz (Silverthorne 45nm)
Chipset Intel 82945G (ICH7)
L2 Cache 512kb
Graphics Intel GMA 950
Memory 1x DDR2 533/667 RAM
Power 24 Pin ATX, P4-connector
Connectors (rear) - 2x PS/2
- 1x Parallel
- 1x D-SUB15 (VGA)
- 1x RS232
- 4x USB 2.0
- 1x LAN 10/100/1000MBit
- 3x Sound (Line Out, Line In, Microphone)
Audio Realtek High Definition Audio
Connectors (internal) - PCI
- Audio
- 4x USB
- 2x SATA
- 1x IDE
Included - D945GCLF2D Mainboard (with 2x 1.6Ghz Atom CPU)
- I/O ATX rear plate
- SATA cable
- IDE cable
- Quickstart-Guide
- Drivers CD
Data sheet Download (PDF)
Data sheet Print view
Please login for creating product ratings.
Your rating:

Please tell us your opinion. Rate the product on a scale from 1 to 5. A value of 5 means the best possible rating. If you want you also can leave a comment.

Your ratings are honored on many ways. Your report will help other customers to better judge about the products. And you can benefit from reports other customers are giving.

In addition we credit 0.50 EUR for each given rating with comment and 1.00 EUR for each given rating with comment (more than 150 characters) on your account. The credit will be substracted automatically on your next order !

We reserve us the right to delete given comments (for example on attempts to give comments with senseless content, copying of other comments, inserting of foreign content, abusing the system for financing orders). "Fair-use-policy" does apply (as of rule of thumb you should give comments for products which you have purchased already. And your credit account only in rare cases will have 2 or even 3 digits). The credit can only be withdrawn by placing an order. It is not possible to get the credit cash or transferred in an other way.

Customer ratings: 5 von 5 Sternen
Average rating, based on 29 ratings
5 von 5 Sternen from sebact am 20.03.2012 | See all my comments

Un buon prodotto, ottimo processore, consumi ridotti, molto efficente.

5 von 5 Sternen from b.martino@mclink.it am 27.12.2011 | | See all my comments
4 von 5 Sternen from eben_holz am 22.12.2011 | | See all my comments
4 von 5 Sternen from Don111111 am 27.09.2011 | | See all my comments

Funktioniert super auch bei höheren Temperaturen super Teil.

4 von 5 Sternen from 2p-tech am 26.11.2010 | | See all my comments

It is still the one of most requested motherboard. Good Motherboard :)

Update from :2011-06-01 09:13
With GSL05 IT WORKS FINE. Cartft it is the last place where we can find this motherboard i think :)

Update from :2011-08-26 09:03
We bought 2 of theese motherboards. 1 of these didn't work. Luckly we are Intel Partner so we had assistance directly from Intel. Then motherboard is always the same. We are still using that in a special fanless system and it works fine
