Jetway JBC420U591-3160-R (Intel Bay Trail-M)

PRODUCT IS CURRENTLY NOT AVAILABLE !
Jetway JBC420U591-3160-R (Intel Bay Trail-M)

  • NUC form factor Fanless system
  • Intel® Braswell N3160 SoC Processor 1.6GHz (up to 2.24GHz)
  • 1 * DDR3L SO-DIMM slot (Max to 8GB)
  • 4 * USB 3.0 (type A)
  • 2 * HDMI
  • 1 * DP
  • 1 * COM
  • 2 * RJ45 (Giga LAN)


Share

RAM :
Dimension (W*D*H) 129 * 109 * 34  mm
Construction Top cover & I/O plate –aluminum; Base- metal
Colors Black / HBJC420U591(W)-3160-B
MB model JNU591-3160
CPU INTEL® Braswell N3160 SoC Processor 1.6GHz (up to 2.24GHz)
BIOS AMI UEFI 64 Mb
Memory 1 * DDR3L SO-DIMM slot (Max to 8GB)
Front I/O Port 2 * USB 3.0 (type A) 1 * COM
Rear I/O Port 2 * USB 3.0 (type A) 2 * HDMI (1.4b) 1 * DP (1.1a) 2 * RJ45 (Giga LAN) 2 * Wi-Fi (option) 1 * Line out/MIC Combo 1 * 12V DC-in jack
Expansion Slot 1 * half size Mini PCI-E slot 1 * full size Mini PCI-E slot for Mini PCI-E /m-SATA Device 1 * SIM card holder
Power Source DC-12V Jack input Adapter : AC_90~240V / DC_12V / 40W
Certification EMC : CE , FCC Safety : RoHS , ErP
Environment Operating Temperature : -0°C~40°C Storage Temperature : -20°C~80°C
Mounting Bracket Multiple use bracket (Wall/VESA/DIN Rail)
­­Packing Net Weight：0.9KG Gross Weight：1.3KG Color Box Dimension：158(W) x 167(D) x 123.6(H) mm
Data sheet Download (PDF)
Data sheet Print view
Jetway Catalog (Rackmount) Download (PDF)
Jetway Catalog (Barebones) Download (PDF)
