USB GPS Receiver (Sirf 3 chipset) incl. Garmin Mobile PC

BACK : GPS Receiver/Software Bundles

PRODUCT IS CURRENTLY NOT AVAILABLE !
Car-PC USB GPS Receiver (<b>Sirf 3</b> chipset) incl. Garmin Mobile PC
USB GPS Receiver (Sirf 3 chipset) incl. Garmin Mobile PC

  • Sirf 3 chipset !
  • Waterproof !
  • Incl. Garmin Mobile PC

Available in 1-3 days 1-3 days 99.95 EUR
incl. 19% VAT, plus shipping .


PRODUCT IS CURRENTLY NOT AVAILABLE !

The GPS receiver features the new chipset SIRF3, is waterproof and has a magnetic and rugged case bottom. The integrated highly sensitive GPS Aaerial gives you a maximum receiption quality.

The connection cable can be enlarged up to 5 meters for optimal placement of the receiver. The integrated USB-to-Serial bridge eases usage. For installation you only need a small USB driver.

Technical details

General spezifications

  • SiRF Star III High Performance GPS Chipset
  • High Sensitiv (Tracking sensivity: -159 dBm)
  • Very short TTFF (Time To First Fix) even with low signal
  • Support of NMEA 0183 protocol
  • Interneral memory for faster re-tracking of position
  • Internal patch aerial
  • Magnetical case bottom
  • Internal USB to Serial bridge
  • Waterproof and rugged casing
  • LED for GPS Status

Specifications

  • Chipset: SiRF Star III
  • Frequency: L1, 1575.42 MHz
  • C/A Code: 1.023 MHz
  • Channels: 20 Kanäle max.
  • Sensivity: -159 dBm
  • Accuracy 10 Meter, 2D RMS
  • Acceleration: 0.1 m/s
  • Time: 1us to GPS time

Date

  • Standard setting: WGS-84

Positioning times

  • Re-Tracking: 0.1 sek., average
  • Hot start: 1 sek., average
  • Warm start: 38 sek., average
  • Cold start: 42 sek., average

Dynamical environments

  • Receiption height: Max. 18,000 Meters (60,000 Feet)
  • Receiption speed: Max. 515 Meter /second (1000 Knoten)
  • Acceleration: Max. 4g
  • Shock: Max. 20m/Sek × 3

Power supply

  • Power connection: 5V DC by USB port
  • Power consumption: approx. 80mA

Interface

  • Protocol type: TTL
  • Output voltage: 0V~2.85V
  • Baudrate: 4,800 bps
  • Output protocol: NMEA 0183 GGA, GSA, GSV, RMC, GLL, opt. VTG


Physical

  • Dimensions: 53mm x 19.2mm
  • Cable length: 1,5 Meters
  • Operation temperature range: -40°C to +85°C
